Beskrivning
Microcontroller based on the AVR RISC architecture.
Max CPU operating frequency: 10MHz
Flash: 1kB
RAM: 64B
EEPROM: 64B
Features
* One 8-bit Timer/Counter with Prescaler and Two PWM Channels
* 4-channel, 10-bit ADC with Internal Voltage Reference
* Programmable Watchdog Timer with Separate On-chip Oscillator
* On-chip Analog Comparator
* debugWIRE On-chip Debug System
* In-System Programmable via SPI Port
* External and Internal Interrupt Sources
* Low Power Idle, ADC Noise Reduction, and Power-down Modes
* Enhanced Power-on Reset Circuit
* Programmable Brown-out Detection Circuit
* Internal Calibrated Oscillator
* 6 Programmable I/O Lines
* Operating Voltage: 1.8 – 5.5V
* Temperature Range: Industrial (-40° to +85°C)
